Autoclave Machine (Steam Sterilizers)

By providing a reliable method for sterilization and decontamination, autoclaves are fundamental to maintaining standards of cleanliness and safety in various critical sectors, ensuring that equipment and materials are free of harmful organisms and safe for their intended use.

What is an Autoclave Machine?

You might be thinking about the autoclave definition so an autoclave machine is a specialized device used to sterilize equipment and supplies by applying high-pressure saturated steam. This device is crucial in environments where sterile conditions are required, effectively using steam to ensure that all tools and materials are free of infectious agents. They leverage the power of steam meaning, which is vaporized water, and high temperatures to sterilize materials and decontaminate biohazardous waste. If you wonder what is autoclaving? Autoclaving is the process of sterilizing materials using pressurized steam. It is a highly effective method for killing microorganisms, including bacteria, viruses, fungi, and spores, by subjecting them to high temperatures and pressure within an autoclave machine. So now you would be able to define autoclave and the meaning of autoclaving.

What Is Sterilization?

Sterilization is the process of removing all microorganisms from objects. It's a way to make sure that something is completely germ-free and safe to use. In other words, it's about making sure there are absolutely no germs left behind. In an autoclave, this is done by exposing items to steam at high pressure and temperature. You place the items inside the autoclave chamber, where they are subjected to steam heated to about 121°C (250°F) for sterilization. The high-pressure environment allows the steam to penetrate every part of the object, ensuring thorough sterilization. This method is essential for ensuring that medical instruments and other critical tools are safe for use without transmitting infections. So, the sterilization definition is all about making instruments super clean and germ-free, and knowing sterilization helps us keep everything safe and healthy.

Purpose of an Autoclave Machine

The primary purpose of autoclaving, also known as steam sterilization, is to use pressurized steam to kill infectious agents and denature proteins. This method of "wet heat" sterilization is highly effective because it penetrates materials quickly and efficiently, ensuring that all microorganisms are destroyed. Autoclaving is considered the most dependable method for sterilizing laboratory equipment and decontaminating biohazardous waste due to its ability to reach temperatures that are much higher than boiling water.

Uses of an Autoclave Machine

At AngelUS Medical, Autoclaves are used for a wide range of sterilization purposes. They provide a physical method for disinfection and sterilization by combining steam, pressure, and time. This method is ideal for:

• Medical Instruments: Sterilizing surgical tools and other medical instruments that come into direct contact with human bodies.
• Laboratory Equipment: Ensuring that glassware, lab instruments, and even some chemicals are sterile, which is essential for conducting accurate and safe scientific experiments.

• Tattoo and Piercing Tools: Sterilizing equipment used in tattoo parlors and piercing studios to prevent the transmission of infections between clients.

• Dental Instruments: Autoclaves are used extensively in dentistry to sterilize instruments between patients, maintaining a sterile environment which is critical in dental procedures.

Types of Autoclaves

Different types of autoclaves are described, along with their specific functionalities and benefits. This section provides valuable information for selecting the appropriate autoclave based on specific needs and requirements. These include auto clave sterilizers, steam sterilizer, and Tuttnauer autoclaves.

Gravity Displacement Autoclaves

• These are the most traditional type of autoclaves. They work by allowing steam to enter the chamber, which forces the cooler air to descend and eventually exit through a drain at the bottom. This process is suitable for most solid items and is commonly used in general laboratories and medical settings.

Pre-vacuum Autoclaves

• Pre-vacuum autoclave  sterilizer first create a vacuum in the chamber to remove air, then fill it with steam. This method is more efficient at removing air from porous loads or items wrapped in surgical packs. The pre-vacuum process ensures that steam can penetrate more quickly and uniformly, making it ideal for complex instruments like surgical kits.

Steam Flush Pressure Pulse Autoclaves

• This type incorporates a series of steam flushes and pressure pulses to remove air from the chamber. Each pulse introduces steam and builds pressure, forcing air out through a vent, then the pressure is momentarily reduced to allow more steam penetration. This method is highly effective for sterilizing large volumes and dense loads, and is particularly useful for items that are difficult to penetrate, such as mattresses or large packs.


Each type of autoclave has its specific uses and benefits, making it important to choose the right one based on the nature of the items to be sterilized and the requirements of the facility. Understanding these differences helps users select the most appropriate autoclave to achieve effective sterilization in their specific applications.

Choosing the Right Autoclave

Different Types of Autoclaves Categorized by Class

Different Types of Autoclaves Categorized by Size (Capacity)

Ritter M7 Speed Clave Sterilizer (Refurbished) Specifications

Tuttnauer T-Edge 11 Autoclave

DeltaClave 600T High Capacity Sterilizer Autoclave

Midmark SoniClean Ultrasonic Cleaner

Pelton & Crane Magna Clave with Mobile Stand

SciCan Statim 2000 Autoclave (Refurbished)

Tuttnauer Valueklave 1730MK

How to Use an Autoclave Effectively

This section offers a step-by-step guide on effectively using an autoclave, covering loading the chamber, closing the door, setting the cycle, monitoring the cycle, and unloading the autoclave. It emphasizes safety precautions and provides a clear process overview. It's also where you can mention autoclave temperature.

1. Loading the Chamber: Make sure the autoclave is operational and has sufficient water. Organize items neatly on the trays, ensuring they do not touch each other for optimal steam circulation. For example, if you're sterilizing laboratory glassware, arrange the pieces so that the openings face downwards, allowing steam to enter and exit the containers.
2. Closing the Door: Securely close the autoclave door. A properly sealed door is crucial to maintain the pressure and temperature required for sterilization. Most autoclaves will have a locking mechanism that confirms when the door is sealed.
3. Setting the Cycle: Choose the appropriate sterilization cycle based on the items' material and the manufacturer's recommendations. For instance, fabrics and porous materials typically require longer exposure to steam than solid metal instruments.
4. Monitoring the Cycle: Wait until the cycle completes and the pressure returns to normal. This is indicated by the pressure gauge or a digital display on the autoclave  sterilizer. Do not attempt to open the autoclave while it's still pressurized.
5. Unloading the Autoclave: Once the pressure is normalized and the temperature has decreased, safely open the autoclave sterilizer . Remove the sterilized items, typically using heat-resistant gloves. Allow items to cool on a clean, dry surface before handling or storage.


Process Overview

• Removing Air: Modern autoclaves often use a vacuum phase to extract air from the chamber, ensuring the steam can reach every surface of the loaded items effectively.

• Heating: The machine heats to a specific temperature, commonly 121°C (250°F), and maintains it for a preset time, usually at least 15-30 minutes depending on the load.

• Sterilization: Steam under pressure penetrates the items, ensuring all microbes are killed.

Maintenance and Safety Tips

• Use Indicators: Always use chemical or biological indicators to confirm that the items reached the necessary sterilization conditions.

• Handle with Care: Be cautious when removing hot items, and never force the autoclave door open while it's pressurized.

Safe Use of an Autoclave

Wear Personal Protective Equipment (PPE)

• Gloves: Always wear heat-resistant gloves to protect your hands from hot surfaces and steam.

• Eye Protection: Wear safety goggles to shield your eyes from splashes, especially when handling liquids.

• Lab Coat and Closed-Toe Shoes: Protect your skin and feet from spills and hot drips by wearing a lab coat and sturdy, closed-toe shoes.

Be Aware of Hot Surfaces

Keep your face and body away from the autoclave door upon opening, as the escaping steam and heat can cause burns.

Load the Autoclave Properly

• Avoid Overloading: Ensure there is enough space around each item for steam to circulate effectively.

• Material Compatibility: Do not place materials that are not autoclave-safe, such as certain plastics or flammable chemicals, inside the machine.

• Inspect Glassware: Check all glassware for any cracks or chips to prevent breakage under pressure.

Use Correct Settings for Different Materials

• Liquids: Always use the liquid cycle for sterilizing fluids to prevent the contents from boiling over and causing damage or injuries.

• Solid Instruments: Use appropriate cycles based on the material type and load size.

Handle Containers Carefully

• Avoid Agitation: Do not shake or agitate containers of liquids that have been autoclaved, as they can be prone to bursting.

• Use Autoclavable Trays: Place all containers on trays designed for autoclave use to catch spills and provide stability.


Cooling Period

Allow all items to cool down inside the autoclave before removal. Handling them too soon can lead to burns or breakage due to thermal shock.

By following these safety measures, you can ensure that the autoclave is used in a safe and effective manner, minimizing the risk of accidents and ensuring that all items are sterilized properly. These precautions help maintain a safe working environment and prolong the life of both the autoclave and the items being sterilized.

Autoclave Maintenance Schedule and Procedures

Common Problems and Solutions

• Temperature Issues: Sometimes autoclaves fail to reach the necessary temperature for sterilization. This could be due to issues like the steam generator's power source being off, needing repair, or a clog in the chamber drain preventing proper steam pressure. It’s crucial to ensure all elements are powered and functioning and that the autoclave’s temperature settings do not exceed its maximum temperature capabilities.

• Load Damage: Autoclaves operate at high temperatures which can damage items that aren't designed to withstand such heat. Plastics may melt and liquids can evaporate or boil over, potentially causing safety hazards. Using autoclave-safe materials and specialized cycles like the Liquids Cycle can help mitigate these issues. Additionally, ensuring cycles are properly set up to prevent burning of sensitive materials like sugars is important.

• Incomplete Sterilization: If goods are not properly sterilized, it poses a risk of contamination. Factors like improper loading, insufficient steam, and selecting the wrong cycle type can affect sterilization. Regularly validating the autoclave with biological indicators can help ensure it is functioning correctly and effectively sterilizing the loads.

• Wet Loads: If items remain wet post-sterilization, this often results from loading techniques where absorbent materials soak up moisture. Arranging items more spaciously or using autoclaves with vacuum capabilities to dry items at cycle’s end can address this issue.

• Handling Large Liquid Loads: When sterilizing large volumes of liquids, the autoclave might abort the cycle if it takes too long to heat the load. Spacing liquids out in smaller containers and using an F0 cycle, which accounts for heat-up time in the total sterilization period, can be effective.

• Steam Supply Problems: No steam in the autoclave jacket can halt the sterilization process. Ensuring the steam generator is powered and that the steam line is properly connected are straightforward fixes.

• Excessive Water or Steam Output: A malfunctioning waste water cooling valve might cause too much water to drain or steam to escape without cooling. Checking and repairing the valve or temperature sensor can correct this.

When to Call a Professional

• Persistent Issues: If problems like temperature inconsistencies or sterilization failures continue despite troubleshooting, professional help may be necessary.

• Mechanical Failures: Issues like broken valves, power problems, or extensive damage to the autoclave require a professional’s expertise.

• Safety Concerns: Whenever there’s a risk of safety, such as with electrical components or pressurized steam, it's safer to consult with a specialist.

Frequently Asked Questions

Why is my autoclave taking longer than usual to reach the required temperature?

This could be due to several factors including an overloaded machine, insufficient water level, or a malfunctioning heating element. Make sure to check that the load is appropriate for your machine's capacity, refill the water as necessary, and consult your manual to troubleshoot heating issues.

What should I do if the autoclave starts showing error messages?

First, refer to your autoclave's manual to understand what the specific error message means. Many common issues can be resolved by resetting the machine or checking for simple issues like a door not properly sealed. If the problem persists, contact the manufacturer's customer service for assistance.

How often should I clean my autoclave and what is the best method to do it?

Regular cleaning is crucial for maintaining your autoclave's efficiency and lifespan. It's recommended to clean the chamber and trays at least once a week using a non-abrasive cleaner and soft cloth. Also, make sure to remove any debris and wipe down the door gasket to ensure a tight seal.

Can I sterilize liquid loads in my autoclave, and if so, how?

Yes, most autoclaves can sterilize liquids, but it requires a specific cycle to prevent the liquids from boiling over. Make sure to use appropriate containers that can withstand high pressure and temperature, and always select the liquid cycle if your machine has this option.

What should I do if my autoclave smells burnt?

A burnt smell usually indicates that some material has adhered to the heater or chamber. Turn off the autoclave and allow it to cool. Clean the interior thoroughly, paying special attention to the heating elements. If the smell persists, it could be a sign of a deeper electrical issue, and you should seek professional help.

How can I ensure the items I am sterilizing are actually sterile?

To ensure effective sterilization, make sure you're using the correct cycle for the type of load and that your autoclave is operating at the correct temperature and pressure. You can use biological indicators to test the sterility of a cycle periodically, which is especially important in medical environments.

What types of materials should I avoid placing in an autoclave?

Do not autoclave flammable, volatile, or corrosive chemicals, as these can cause dangerous reactions under high pressure and temperature. Also, avoid autoclaving items made from non-heat-resistant plastics, as they can melt and damage your machine.
